How to prevent and deal with common faults of water purifier pressure gauge

In modern industrial environment, water purifier pressure gauge is one of the key equipment, and its performance stability is crucial to the operation of the whole system. However, various faults may occur during the use of the equipment, which not only affects the normal operation of the equipment, but also may lead to reduced production efficiency. The following will conduct an in-depth analysis of common fault types and their causes, and propose effective prevention and response strategies.
Among the common fault types, unqualified indication is the most common situation. The main reason is usually due to the incorrect angle between the pull rod and the fan gear, or the eccentricity of the center axis. This inaccuracy of indication directly affects the operator's judgment of the system pressure, which may lead to unstable operation of the equipment. In addition, elastic deformation is also an obvious fault manifestation, especially in the process of continuous calibration. If the readings are inconsistent and the values ​​gradually increase when the pressure is increased and decreased, it often indicates that the elastic element inside the pressure gauge may have been damaged.
Another common problem is that the pointer moves unsteadily, which may be caused by a variety of factors, including blockage of the gasket, dirt at the gear connection, scattered hairspring, and jamming of the moving part of the movement. The unsteady movement of the pointer will interfere with the monitoring of the system pressure and affect the accuracy of the data. At the same time, the error caused by the pointer jumping is also a problem that cannot be ignored. The blockage of the pipeline, the friction between the pointer and the surface, and the dirt at the connection between the center shaft and the fan gear may cause the pointer to jump, resulting in significant measurement errors. In addition, the phenomenon of the pointer deviating from the zero position also occurs from time to time. This is usually caused by the loosening of the fastening screws of the transmission mechanism, the bending or loosening of the pointer due to the excessive pressure reduction speed, or the permanent deformation of the spring tube.
In order to effectively prevent the occurrence of the above faults, regular maintenance and inspection are indispensable. We recommend that users regularly perform comprehensive maintenance on the water purifier pressure gauge, including cleaning dirt, checking gear connections, and tidying up the hairspring to ensure the normal operation of the equipment. At the same time, for wearing parts such as elastic elements and gaskets, users should regularly check and replace them in time to prevent failures caused by aging of components.
In addition, standardized operating procedures and systematic training are also important links in preventing faults. We provide users with detailed operation manuals and training services to ensure that operators can master the use of water purifier pressure gauges, so as to avoid failures caused by improper operation. It is recommended that users establish a set of standardized operation procedures and conduct regular training for operators to improve the overall operation level and ensure that the equipment operates in the best condition.

What are the requirements for the installation environment of water purifier pressure gauge?

In the application of water treatment equipment, the performance of Water Purifier Pressure Gauge is directly related to the operating efficiency and safety of the system. Therefore, it is particularly important to ensure that it is installed and used in a suitable environment.
First of all, the control of temperature and humidity is an important factor affecting the performance of Water Purifier Pressure Gauge. JRL recommends that the installation environment temperature of the instrument be kept between -40℃ and +60℃, and the relative humidity should not exceed 80%. Too high or too low temperature and excessive humidity may cause irreversible damage to the electronic components, elastic components and sealing materials inside the instrument, thereby affecting the accuracy and stability of its measurement. Especially in high temperature and high humidity environments, the metal parts inside the instrument are prone to corrosion, and the sealing materials may cause leakage or inaccurate readings due to aging. Therefore, reasonable control of environmental conditions is the basis for ensuring the long-term stable operation of the instrument.
Secondly, the protection against vibration and shock cannot be ignored. Water treatment equipment will inevitably generate certain vibration and shock during operation, which puts strict requirements on the installation environment of Water Purifier Pressure Gauge. The instrument should be installed in an area with less vibration and shock as much as possible, avoiding direct proximity to the vibration source or shock source. If this situation cannot be avoided, effective shock reduction measures should be taken, such as installing shock absorbers or using flexible connections, to significantly reduce the impact of vibration and shock on the instrument.
In addition, cleaning and dust prevention are also important links to ensure the performance of Water Purifier Pressure Gauge. JRL recommends that before installing the instrument, the installation pipeline must be thoroughly cleaned to remove dust, impurities and other contaminants. During the installation process, it is crucial to ensure that the joints, threads and other parts of the instrument are not contaminated. At the same time, an installation location that avoids dust accumulation as much as possible should be selected to reduce erosion and contamination of the internal components of the instrument, thereby ensuring its long-term stable operation.
Furthermore, the installation position and direction also have a significant impact on the performance of Water Purifier Pressure Gauge. JRL points out that the meter should be installed in a position that is convenient for observation and maintenance, and the dial should generally not be placed horizontally, but should be tilted at a certain angle to facilitate the operator to read the indication. The installation position of the meter should be as close to the pressure measuring point as possible to reduce pipeline resistance and pressure loss. In addition, during the installation process, it is necessary to ensure that the meter is perpendicular to the installation direction to avoid measurement errors caused by improper installation.
Finally, electromagnetic interference protection is also an issue that cannot be ignored in modern water treatment systems. JRL reminds users that when installing the Water Purifier Pressure Gauge, try to avoid placing it near strong electromagnetic fields, such as near high-power motors, inverters and other equipment. If it cannot be avoided, effective electromagnetic shielding measures should be taken to reduce the impact of electromagnetic interference on the meter, thereby ensuring the accuracy and reliability of its measurement.
