Nominal size | Y26/Y27/37/40/45mm |
Scale range | 0-3bar、4bar、6bar |
Accuracy class | CL2.5 |
Capillary material | Copper、PE |
Capillary length | 300mm、500mm、650mm、Customizable |
Connection material | Copper、PE |
Connection | G1/4、M14*1、Plug-in、Customizable |
Case | PA66/ABS |
The Y28 pressure gauge is a high-precision, durable pressure measuring instrument that is widely used in industrial equipment, HVAC systems, and various fluid application scenarios. Its excellent performance and reliable material selection make it an ideal choice for your equipment monitoring.
Product Features
Diverse size options: The Y28 pressure gauge is available in a variety of models, including Y26, Y27, Y37, Y40, and Y45mm, which can meet different equipment and installation needs.
Wide measurement range: The measurement range of this product ranges from 0-3bar to 4bar and 6bar, which is suitable for a variety of working environments, ensuring that you can accurately measure the required pressure value.
Excellent accuracy: The Y28 pressure gauge has an accuracy level of CL2.5, which means that it has high accuracy in pressure measurement, helping you reduce errors and improve work efficiency.
Durable materials: The use of high-quality copper materials as capillaries and connectors ensures the durability and corrosion resistance of the product, and can work stably in harsh environments.
Customization options: Capillaries of different lengths such as 300mm, 500mm and 650mm are available, and can also be customized according to customer needs, flexibly adapting to various installation conditions.
Multiple connection methods: The Y28 pressure gauge supports multiple connection methods such as G1/4, M14*1, plug-in, etc., and can also be customized according to needs, facilitating seamless connection with existing equipment.
High-quality shell material: The shell is made of PA66/ABS material, which has good impact resistance and heat resistance, ensuring the reliability of the product under various conditions.
